Davies Craig 14-Inch Slimline Thermatic Electric Fan; 24-Volt (Universal; Some Adaptation May Be Required)

Description

_x000D__x000D_

High-Performance Electric Water Pump. The Davies Craig EWP150 Black Remote Electric Water Pump 12V enhances engine cooling efficiency for high-performance and forced-induction engines. It is designed for remote mounting, ensuring optimal heat management in turbocharged, supercharged, or heavily worked engines where additional cooling is critical. This pump helps reduce engine temperature, improving overall vehicle performance and reliability.

_x000D__x000D_

Construction and Appearance. Constructed from rugged aluminum with a matt black powder-coated finish, the pump features a compact, stylish alloy design built to withstand harsh engine bay environments. The pump incorporates a clockwise centrifugal design with a volute chamber and a ceramic face seal for durability and efficient coolant flow.

_x000D__x000D_

Installation. Installation is moderately straightforward, typically requiring mounting in the bottom radiator hose and possible belt adjustments if disabling or removing the mechanical water pump. Soft mounting is recommended to reduce vibration, and certain installations may require minor modifications to radiator hoses or belt routing without extensive drilling.

_x000D__x000D_

Application. Fits universal; some adaptation may be required. Ideal for use in engine cooling systems for high horsepower, turbocharged, supercharged, or otherwise heavily modified engines that generate excess heat, requiring enhanced coolant circulation and temperature management.

Davies Craig DC-0165

CA Residents: WARNING: Cancer and Reproductive Harm

_x000D_
• Celebrating 50 Years Remote-Mounted Electric Water Pump

_x000D_

• Attractive Matt Black Powder-Coated Alloy Design

_x000D_

• Available As Pump Only, Kit Or Combo With Controller

_x000D_

• Designed For Higher Horsepower, Turbocharged, Supercharged Engines

_x000D_

• Compact Unit With -AN16 Internal Inlet And Outlet Fittings

_x000D_

• Rugged Aluminum Hi-Flow Electric Water Pump

_x000D_

• Increases Power And Improves Coolant Temperature Control

_x000D_

• Operating Voltage Range From 3 To 15 Volts DC

_x000D_

• Maximum Current Is 10 Amps At 13 Volts

_x000D_

• Maximum Flow Rate Of 162 Liters Per Minute (42.8 Gallons Per Minute)

_x000D_

• Operating Temperature Range From -40 To 120 Degrees Celsius

_x000D_

• Clockwise Centrifugal Pump Design With Volute Chamber

_x000D_

• Pump Weight Of Approximately 1170 Grams (2.6 Pounds)

_x000D_

• Aluminum Powder-Coated Pump Material

_x000D_

• Burst Pressure Rating Up To 500 Kilopascals (72.5 Psi)

_x000D_

• Ceramic Face Seal For Durability

_x000D_

• Not A Self-Priming Pump

_x000D_

• Fits Hose Sizes From 35mm To 51mm (1.38 To 2 Inches)

_x000D_

• Push-On Fittings Available In Sizes 38mm, 44mm, And 51mm With Sleeves

_x000D_

• Inlet And Outlet Use -16AN ORB Internal Fittings

_x000D_

• Fits Universal; Some Adaptation May Be Required
