Description
HIGH-PERFORMANCE IGNITION COIL. The PerTronix 3-Pin Flame-Thrower Coil; Single delivers enhanced spark energy to improve ignition system performance, ensuring reliable combustion and engine efficiency. It serves as a direct OEM replacement designed to meet the rigorous demands of modern engines, especially under high RPM and boosted conditions.
CONSTRUCTION AND APPEARANCE. Crafted with epoxy molding for moisture resistance and durability, the coil features a matte finish and plated copper terminals for superior current conduction. The high-temp boot maintains a secure seal and form, while the integrated mounting bracket allows straightforward factory-position installation without additional hardware.
INSTALLATION. This coil installs easily as a direct factory replacement with no drilling or modifications required, making it a straightforward upgrade for performance or stock ignition systems. It is designed to fit seamlessly with coil-on-plug ignition setups.
WARRANTY. The coil is covered by a one-year limited warranty protecting against defects in material and workmanship.
APPLICATION. Engineered for the 2011 through 2020 Ford F-150 equipped with the 3.5L EcoBoost V6 engine, providing optimized ignition performance tailored to this specific model and powertrain combination.
PerTronix 30771
CA Residents: WARNING: Cancer and Reproductive Harm
- 30,000 Volts Direct OEM Replacement
- Optimized Coil Design Yields At Least 15% More Energy Available For The Spark Than Common OEM Coils
- Provides Spark Energy Throughout The RPM Range With No Energy Degradation Up To 11,000 Engine RPM
- Plated Copper Terminals For Enhanced Current Conduction
- Moisture Resistant Construction For Long Life In Harsh Environments
- High-Temperature Boot Maintains Seal And Form
- Epoxy Molded For Shock And Vibration Resistance
- Late Model Coil-On-Plug Series Optimized To Improve Spark Capabilities Of Modern Ignition Systems
- Coils Are Epoxy Molded To Prevent Premature Failure From Moisture Or Winding Fatigue
- Designed To Meet Increased Ignition Demand From Superchargers, Turbochargers, And Nitrous
- Flame-Thrower Coils Deliver Increased Spark Energy For Both Performance And Stock Ignitions
- Maximum Voltage: 30,000 Volts
- Primary Resistance: 0.5 Ohms
- Voltage: 12 Volts
- Coil Type: Coil Pack
- Finish: Matte
- Ignition Type: Computer Controlled
- Coil Shape: Same As Factory
- Mounting Position: Factory
- Mounting Bracket Included: Integrated
- Coil Wire Attachment: Coil-On-Plug
- Requires No External Resistor
- Coil Internal Construction: Epoxy Molded
- Primary Inductance: 2.2 H
- Secondary Resistance: 9000 Ohms
- Turns Ratio: 85:1
- Grade Type: Stock Replacement
- Fits 2011-2020 3.5L EcoBoost Ford F-150
